32-ch 1.5U 4K NVR
Incoming Bandwidth 256 Mbps
Outgoing Bandwidth 160 Mbps
HDMI Output 4K/30Hz, VGA Output 1080/60 Hz
HDMI/VGA independent output
Smart Function : Support multiple VCA (Video Content Analytics) events, Configurable
special camera smart functions, such as VCA detection (motion, line crossing, intrusion,
etc.), heat map, ANPR, and people counting
Audio Output 1-ch, Two Way Talk, Alarm I/O 16/4
H.265/H.265+/H.264+/H.264/MPEG4, up to 12MP, Playback 16-ch,
Decoding Capability 1-ch@12MP (30fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-
ch@1080p(30 fps)
2, RJ-45 10/100/1000 Mbps
4 SATA HDDs up to 10TB for each port
100 to 240 VAC, 50 to 60Hz, Working Temperature -10 °C to 55 °C (14 °F to 131 °F),
Working Humidity 10 to 90 %
